Data Logger
LOG-DL300
The LOG-DL300 is a compact panel-mounted data logger with display, communication, data logging, and IoT connectivity for local and remote monitoring.
1 / 3- 7" TFT Touchscreen Display
- Real-Time Monitoring & Data Logging
- Alarm & Event Management
- RS485 Modbus & Ethernet
About the Data Logger LOG-DL300
The LOG-DL300 is a compact panel-mounted data logger with display, communication, data logging, and IoT connectivity for local and remote monitoring.
Key features
- 7" TFT Touchscreen Display
- Real-Time Monitoring & Data Logging
- Alarm & Event Management
- RS485 Modbus & Ethernet
- Linked IoT Cloud & FOTA
Data Logger technical specification
Download PDF- Supply Voltage
- 24 VDC
- Display
- 7-inch TFT LCD Touch Screen
- Communication
- 2 x RS485, 2 x Ethernet, GSM(Optional)
- USB
- USB data export / configuration use
- Wireless Connectivity
- External antenna for supported wireless / cloud connectivity
- Mounting
- Panel mount
- Front Protection
- IP65
- Dimensions (W x H x D)
- 230 x 150 x 30 mm
- Panel Cutout
- 217 x 139 mm
- Operating Use
- Indoor industrial panel installation
Applications of the Data Logger
- 01Industrial Automation
- 02Cold Storage & Refrigeration
- 03Pharmaceutical & Food Industries
- 04Water & Wastewater Systems
- 05BMS & Environmental Monitoring
- 06Industrial IoT Applications
